Purposes and Phases of a Soils Investigation

Before any structure can be safely and economically constructed, one of the first and most important steps is to understand the soil beneath it. That’s where a soils investigation (or geotechnical investigation) comes in. This process gives engineers, architects, and developers the critical information needed for making informed design and construction decisions.

Let’s explore the purpose, importance, and phases of a soil investigation in detail.

Why is a Soils Investigation Important?

A soils investigation isn’t just a procedural step—it’s the foundation of the foundation. Its results influence structural design, project cost, construction techniques, and risk management.

Main Purposes of a Soils Investigation

1. Site Suitability
   To determine if the ground conditions are appropriate for the proposed structure or project.

2. Design Efficiency
   To allow engineers to make economical, safe, and optimized designs for foundations and earthworks.

3. Anticipate Construction Challenges
   To detect groundwater issues, unstable soil layers, frost-susceptible zones, or other local complications that may arise during construction.

4. Environmental and Due Diligence Assessment
   It also helps in project feasibility studies, particularly for real estate, industrial setups, and large infrastructure projects.

Phases of a Soils Investigation

The scope of the investigation depends on:

• Project type, size, and importance

• Client’s risk tolerance and budget

• Engineer’s familiarity with local soil

• Local building codes and regulations

A complete soils investigation is conducted in five key phases, from research to reporting.

Phase I: Desk Study (Preliminary Study)

Also known as the "data gathering" stage, this phase involves collecting all existing information about the site.

Data Collected:

• Project plans (type, size, loading, importance)

• Previous geotechnical reports

• Geological and topographic maps

• Satellite imagery (Google Earth, GIS systems)

• Aerial photos, seismicity records, drainage maps

• Newspaper clippings, flood records

Tools like Google Earth and USGS databases are useful for accessing terrain, contours, and site history.

Phase II: Preliminary Reconnaissance (Site Visit)

This is a physical inspection of the site to observe surface features and verify data from the desk study.

Key Observations:

• Photographs of site surroundings

• Access routes for equipment and materials

• Sketches showing fences, utilities, drains, walkways

• Topography (cuts, fills, depressions, water ponds)

• Nearby structures and any damage (cracks, tilt, mold)

• Exposed geology (road cuts or natural outcrops)

Occasionally, trial pits or shallow boreholes may be dug at this stage.

Phase III: Detailed Soils Exploration

This is the core investigation phase, involving subsurface exploration and sample collection.

Goals of This Phase:

• Identify soil strata, thickness, and continuity

• Determine groundwater level and seasonal fluctuation

• Collect disturbed and undisturbed samples for testing

• Conduct in situ tests (e.g., SPT, DCPT, SCPT)

Common Equipment:

• Auger drills

• Rotary drilling rigs

• Cone penetration testing tools

• Percolation test kits

Phase IV: Laboratory Testing

Collected samples are tested to determine engineering properties of the soil.

Typical Lab Tests:

• Grain size distribution

• Atterberg limits (for plasticity)

• Specific gravity and moisture content

• Compaction (Proctor test)

• Shear strength (triaxial, direct shear)

• Consolidation and permeability

• Swell/shrink tests (for expansive soils)

Not all tests are required for every project; testing depends on the structure and site conditions.

Phase V: Geotechnical Report Preparation

The final deliverable of the soils investigation is a clear, detailed, and actionable geotechnical report.

Contents of the Report:

• Site description and location

• Soil stratigraphy and classification

• Field exploration methods and test results

• Groundwater conditions

• Engineering properties of soil

• Foundation recommendations

• Construction challenges (if any)

• Frost susceptibility, drainage, waterlogged areas

The report must help designers, contractors, and project owners understand the site's behavior under loading.

 Summary Table: Phases of Soil Investigation

Phase	Name	Main Activities
I	Desk Study	Literature review, satellite imagery, previous records
II	Site Reconnaissance	Visual inspection, sketching, access evaluation
III	Detailed Exploration	Boreholes, SPT, SCPT, sampling, groundwater analysis
IV	Laboratory Testing	Classification, strength, permeability, compaction tests
V	Report Writing	Full documentation with design and construction guidance

Pro Tip for Engineers

Avoid skipping or minimizing soil investigations to cut costs. It often results in unforeseen problems, such as:

• Foundation failure

• Excessive settlement

• Construction delays

• Litigation due to unsafe structures

It’s better to invest in a detailed geotechnical investigation upfront than to risk costly remediation later.
